Link 5 Bar MAP Sensor EU (MAP5EU) - 101-0295

Part Number: 101-0295
Authorized Link ECU Dealer Ships from Calgary
Link Black Friday Sale: long ETA We place our Link sale order after the sale ends on Nov 30. Sale orders usually arrive in Calgary in early 2027. Need it sooner? Contact us before you order. support@boostfactory.ca

Warehouse Icon Inventory Location: Manufacturer Warehouse USA

Stock: 0

Link 5 Bar MAP Sensor EU (MAP5EU) - 101-0295

The Link 5 Bar MAP Sensor is a high-accuracy manifold absolute pressure (MAP) sensor designed for turbocharged and supercharged engines operating at up to 58 psi (4 bar) of boost. Featuring a rugged stainless steel construction and fast response time, it delivers stable and accurate pressure measurement for reliable engine tuning in demanding motorsport and performance applications.

Suits: All Link ECUs. Other aftermarket ECUs with a 5V ratiometric analogue input. Turbocharged and supercharged engines running up to 58 psi (4.0 bar) of boost.

Includes: MAP Sensor 5 Bar, TI Sensor Connector Kit, Printed Accessory instructions.

Specifications

  • Pressure range: -1 to +4 bar (-14.5 to +58 psi)
  • 0.5-4.5V ratiometric output
  • 5V supply voltage
  • High-accuracy piezoresistive sensing element
  • Stainless steel housing
  • Fast response time (<1ms)
  • Excellent vibration and shock resistance
  • Operating temperature: -40degC to +125degC
  • IP66 rated
  • Packard Metri-Pack connector
  • 1/8" NPT Male pressure port
  • Comes with TI Sensor Connector Kit
  • Product Dimensions: 70mm(L)x30mm(W)x30mm(H); 2.76in(L)x1.18in(W)x1.18in(H)
  • Product Weight: 65 grams (2.29 ounces)
  • Electrical: Operating Voltage Range: 5V; Maximum Input Voltage: 5V
  • PCLink Calibration Name: "5 Bar Variohm"
  • 0.5V = 0kPa, 4.5V = 500kPa
  • Connector: TI Sensor Connector Kit 101-0130

Notes

  • Designed for use with a regulated 5V sensor supply.
  • Using Link G4/G4+/G4X/G5 ECU's select the MAP sensor type in PC Link as 'Variohm 5 Bar'.
  • Not recommended for naturally aspired engines or boost levels exceeding 4 BAR / 58psi.
