LINK 8 Bar MAP Sensor EU (MAP8EU) 101-0298

The Link 8 Bar MAP Sensor is a high-accuracy manifold absolute pressure (MAP) sensor designed for turbocharged and supercharged engines operating at up to 101 psi (7 bar) of boost. Featuring a rugged stainless steel construction and fast response time, it delivers stable and accurate pressure measurement for reliable engine tuning in demanding motorsport and high-performance applications.

Models Supported

• All Link ECUs.
• Other aftermarket ECUs with a 5V ratiometric analogue input.
• Up to 101 psi (7 bar) boost pressure.

Warnings

• Designed for use with a regulated 5V sensor supply.
• Using Link G4/G4+/G4X/G5 ECU's select the MAP sensor type in PC Link as 'Variohm 8 Bar'.
• Not recommended for naturally aspired engines or boost levels exceeding 7 BAR / 101 psi.

Specifications

The Link 8 Bar MAP Sensor has the following specifications:

• Pressure range: -1 to +7 bar (-14.5 to +101 psi).
• 0.5-4.5V ratiometric output.
• 5V supply voltage.
• High-accuracy piezoresistive sensing element.
• Stainless steel housing.
• Fast response time (<1ms).
• Excellent vibration and shock resistance.
• Operating temperature: -40degC to +125degC.
• IP66 rated.
• Packard Metri-Pack connector.
• 1/8" NPT Male pressure port.
• Comes with TI Sensor Connector Kit.
• Product Dimensions: 70mm(L)x25mm(W)x25mm(H) / 2.76in(L)x0.98in(W)x0.98in(H)
• Product Weight: 65 grams (2.29 ounces)
• Electrical: Operating Voltage Range: 5V; Maximum Input Voltage: 5V
• What's in the Box: MAP Sensor 8 Bar EU, TI Sensor Connector Kit, Printed Accessory instructions
• PCLink Calibration Name: 8 Bar Variohm
• Raw Calibration Specs: 0.5V = 0kPa, 4.5V = 800kPa
• Connector: TI Sensor Connector Kit 101-0130
