Radium Engineering Remote Mount Vented Female Dry Break 1.5 in - 20-1004-V

Radium Engineering 20-1004-V remote mount vented female dry break, 1.5 in, universal for any 1.5 in ID filler hose.

• Mounts remotely to an external surface such as a fender; requires a 77 mm (3.03 in) hole
• Vented cap with roll-over protection
• Aluminum housing and aluminum nut ring with stainless hardware
• Compatible with all listed fuel types
• 1.5 in barbed outlet can be swapped by removing six screws
• Flange OD 4.75 in, 4.25 in bolt circle, height 4.08 in (dry break to barb)
• Mates with the 20-0996 (or 20-0496) male dry break, PRV

Included

• Remote mount housing
• Dry break receptacle
• 1.5 in barb adapter
• Threaded mounting ring
• Gasket
• Stainless steel hardware

Fitment

• Universal, fits any 1.5 in ID filler hose. (Source: Radium Engineering)
