GKTech - S13 240sx/R32 Skyline subframe anti-squat reduction weld in kit - S13X-RLCA

Part Number: S13X-RLCA
Authorized GK Tech Dealer Ships from Calgary
Special Order From GK Tech Australia In stock at GK Tech. Order now and it goes on our next GK Tech order, placed on Nov 29th. Estimated arrival in Calgary is the week of Dec 7th - Dec 11th. support@boostfactory.ca

Warehouse Icon Inventory Location: Manufacturer Warehouse USA

Stock: 0

GKTech S13 240SX/R32 Skyline Subframe Anti-Squat Reduction Weld-In Kit, part number S13X-RLCA. Weld-in brackets that relocate the rear lower control arm front pick up point for more rear grip.

  • Designed from a 3D scan with CMM data. Laser cut steel brackets with step by step instructions
  • Relocates the front pick up point of the rear lower control arm nearly 2 inches lower, copying the S14/S15 geometry
  • Anti-squat drops from 45% to 0% for more traction on corner exit and over bumps
  • Roll center is raised 20 mm for more roll stiffness. Anti-lift is reduced from 80% to 20%. Bump steer is reduced by 6 mm at 100 mm compression/rebound
  • The subframe does not need to be removed, but welding is required and gluing the brackets in would not be as effective
  • With adjustable traction arms, the suggested length after fitting is 225 mm, center hole to center hole
  • Complies with the 2020 Formula Drift rule allowing subframe tabs within 2 inches of the original mounting position
  • Note: because of the added bushing misalignment, aftermarket rear LCAs with spherical bearings, or a spherical bearing conversion of the OEM rear LCAs, are recommended

Fitment

  • Nissan S13 240SX (CA18, SR20)
  • Nissan S13 Silvia (CA18, SR20)
  • Nissan S13 180SX (CA18, SR20)
  • Nissan R32 Skyline GT-R
  • Nissan R32 Skyline GTS-T
  • Nissan Cefiro A31
  • Nissan Laurel C33
  • Nissan Z32 300ZX

Contact us if you are unsure of fitment or Size HERE
